Water level measurement on ship

Draft depth measurement of ship
 Water level measurement on ship


Water level measurement on board to ensure the safety of the ship, used to determine the draft (draft, trim) of the ship's position. Typically, one measurement point is at the bow and the other at the stern. If the ship is larger, two additional measurement points are often added, one in the middle of the hull, one on the port side and one on the starboard side. In order to be able to accurately determine the hull position and draft, it is necessary to be able to accurately measure the water level.

Process data

Measuring task Level measurement
Measuring point Pipe
Measuring range up to 10 m
Medium Water、seawater
Process temperature 0 ... +30 ℃
Process pressure 0 ... 0 bar
Special challenges Marine license, sea water with corrosive, sensor with submerged

Fast delivery and comprehensive support

SKE provides customers with a series of full support from product selection to production, sales and after-sales through mature production technology and comprehensive service system.
