80GHz Radar Water Level Sensor(Stainless Steel Shell)
  • 80GHz Radar Water Level Sensor(Stainless Steel Shell)
  • 80GHz Radar Water Level Sensor(Stainless Steel Shell)
  • 80GHz Radar Water Level Sensor(Stainless Steel Shell)
  • 80GHz Radar Water Level Sensor(Stainless Steel Shell)

80GHz Radar Water Level Sensor(Stainless Steel Shell)

Water and wastewater industry
The 80GHz Radar Water Level Transmitter has been specially developed for the needs of the water, wastewater treatment. The super lightweight 0.5 kg) and fittings can be selected as needed and only require minimal effort to install. This end-to-end concept allows simple integration and fast maintenance – it also reduces spare parts inventories and production downtime.
water level monitoring Open channel water level Measuring River water level urban flooding radar water level sensor

  • Simple installation and debugging
    Simple installation and debugging
    Simple installation,no maintenance, convenient debugging (mobile APP, WeChat applet debugging), long life.
  • Various signal output
    Various signal output
    A variety of output circuit interfaces cooperate with the acquisition system
    Signal output: RS485/ 4-20mA/Modbus,etc.
  • Continuous signal acquisition
    Continuous signal acquisition
    Uninterrupted work, continuous online acquisition of signals.
  • Wireless transmission
    Wireless transmission
    No need to excavate cable trenches, no impact on the construction of channel lining, tree planting and other projects.
  • Strong anti-interference ability
    Strong anti-interference ability
    Narrow emitting angle: ±5°.
    Energy is concentrated, stronger anti-interference ability, improving the accuracy and reliability of the measurement.
  • 80GHz Radar Water Level Sensor(Stainless Steel Shell)
    Principle

        Frequency modulation continuous wave (FMCW) technology is adopted in the object level meter of 80GHz radar level transmitter. The continuous wave with frequency variation is transmitted within a certain period, and the echo reflected by the object has a certain frequency difference with the transmitted signal. The distance information between the target and the radar can be obtained by measuring the frequency difference.

Application area

  • Open channel water level monitoring
    Automatic monitoring of seasonal rivers, not suitable for underwater installations.
  • Flash flood warning
    Monitoring of the tail water level in front of the reservoir dam, under the dam, and the water level of the surge tower (well).
  • Urban waterlogging
    Under the influence of heavy rainfall in urban low-lying terrain areas, the drainage system is overloaded, which can easily cause urban waterlogging and cause immeasurable loss of life and property to citizens. Using radar water level gauge to monitor its water level is an effective means of guarantee.
  • Sewage Disposal
    City water supply, sewage level monitoring system.
  • Gate station water level monitoring
    Data collection is carried out for the water level of the river. When the water level of the inland river is lower or higher than the warning line, a signal is output to the central control system, so that the station gate can realize real-time monitoring of the water level.
  • Open channel water level monitoring
    Automatic monitoring of seasonal rivers, not suitable for underwater installations.
  • Flash flood warning
    Monitoring of the tail water level in front of the reservoir dam, under the dam, and the water level of the surge tower (well).
  • Urban waterlogging
    Under the influence of heavy rainfall in urban low-lying terrain areas, the drainage system is overloaded, which can easily cause urban waterlogging and cause immeasurable loss of life and property to citizens. Using radar water level gauge to monitor its water level is an effective means of guarantee.
  • Sewage Disposal
    City water supply, sewage level monitoring system.
  • Gate station water level monitoring
    Data collection is carried out for the water level of the river. When the water level of the inland river is lower or higher than the warning line, a signal is output to the central control system, so that the station gate can realize real-time monitoring of the water level.

Technical parameters

  • Radar Level
    Two wire system
  • Measuring range - Distance
    10m/20m
  • Accuracy
    ±2 mm
  • Signal output
    4~20mA/RS-485/Bluetooth
  • Power supply
    DC 24V ( 22V~30V )
  • Ambient temperature
    -20℃~+70℃
  • Process Temperature
    -20 ℃ to 60 ℃ (-20 to +140°F)
  • Ambient humidity
    (0%~95%)RH
  • Process Pressure
    Normal atmospheric pressure
  • Weight
    0.5 kgs
  • Sizes
    ϕ76mm×107mm
  • Material
    Stainless steel
  • Protection rating
    IP67
